Durable Slurry Wet Magnetic Separator Ceramic Diagram 380v Easy To Operate ISO9001:2008

Durable Slurry Wet Magnetic Separator Ceramic Diagram 380v Easy To Operate ISO9001:2008
Durable Slurry Wet Magnetic Separator Ceramic Diagram 380v Easy To Operate ISO9001:2008 Durable Slurry Wet Magnetic Separator Ceramic Diagram 380v Easy To Operate ISO9001:2008 Durable Slurry Wet Magnetic Separator Ceramic Diagram 380v Easy To Operate ISO9001:2008

Large Image :  Durable Slurry Wet Magnetic Separator Ceramic Diagram 380v Easy To Operate ISO9001:2008

Product Details:
Place of Origin: FOSHAN,CHINA
Brand Name: ZT
Certification: ISO9001:2008
Model Number: 7A300
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Film And Wooden Case
Delivery Time: Within 25 days after the advance payment is made
Supply Ability: 50 SETS PER MONTH

Durable Slurry Wet Magnetic Separator Ceramic Diagram 380v Easy To Operate ISO9001:2008

Description
Weight: According The Capacity Warranty: 1 Year
Voltage: 220-480 After-sales Service Provided: Online Support,Video Technical Support
Type: Magnetic Separator Condition: New
Production Capacity: Depend On The Model Application: Mining,mineral Beneficiation
Installation: Under Guidance Power(w): 1.1-11KW
High Light:

magnetic roller separator

,

dry drum magnetic separator

Durable Slurry Wet Magnetic Separator Diagram 380v Easy To Operate



We would like to take the privilege of introducing ourselves as the most trusted manufacturer and exporter of Wet High Intensity Magnetic Separators. Precisely designed at our state of the art machining facility, these separators are made using quality materials procured from authentic vendors of the market. Our Wet High Intensity Magnetic Separators are used for filtering and separating iron and non metallic materials from hematite, limonite, ilmenite, manganese, wolframite and tantalum-niobium. We hold the expertise to customize these separators as per needs of the clients.



Features:

  • Require very less energy to operate
  • Totally-enclosed and removable dust-proof housings for self-cleaning
  • Low maintenance, easy installation and advance service life

Operation process



Firstly, power on ,then open the admission valve and slurry valve, close the back slurry valve and iron discharging valve, then magnetizing.

After a few minutes later(you can set the time what you like depending on yourself condition),close the admission valve and slurry valve, open the back slurry valve to discharge the remaining slurry in the separator, then magnetic cutting, close the admission valve, slurry valve and back slurry valve, open the iron discharging valve to discharge the magnetic material which are absorbed on the magnetic media.



Application scope



Electromagnetic slurry separators are widely used in the ceramic, mine, chemical, electron, and food industries to remove the iron and magnetic material from those raw material.

For example:

organic chemical industry and related equipment,organic chemical industry and  related equipment, Fine chemicals and  related equipment,paper treatment ,paper pulp treatment,fiber stuff treatment,food  treatment ,flavoring treatment ,grain and oil treatment,water treatmen ,Quartz Beneficiation,Sodium potassium feldspar  Beneficiation,Kaolin Beneficiation



Technical parameters of contrast



Model

1.5A160

3A89

3A190

7A250

7A300

11A250

18.5A250

Magnetic field strength(T)

2.5

2.5

2

3

3

3.5

3

Input voltage(ACV)

220

380

220

380

380

380

380

Maximumoutput current(DCA)

7

7

10

18

18

20

32

Maximum coil power(KW)

1.5

3

3

7

7

11

18.5

Insulation method

E

E

E

E

E

E

E

Cooling method

water and oil double cooling

water and oil double cooling

water and oil double cooling

water and oil double cooling

water and oil double cooling

water and oil double cooling

water and oil double cooling

Magnetic lumen diameter(mm)

160

89

190

250

300

250

250

yield

(m³/h)

1-1.5

0.2-0.5

5-10

10-25

10-30

10-25

10-30

dimension(mm)

1200*1200

*1850

850*750*

1000

1000*950*

1550

1320*1200*

1850

1200*1200*

1850

1320*1200*

1850

1400*1400*1850

Main machine weight(KG)

180

250

510

1050

1070

1210

1500

Usage

Applicable for 40-400 mesh feedstock of iron elimination





Durable Slurry Wet Magnetic Separator Ceramic Diagram 380v Easy To Operate ISO9001:2008 0



Durable Slurry Wet Magnetic Separator Ceramic Diagram 380v Easy To Operate ISO9001:2008 1
