Product Details:
|
| Operation: | Automatic | Name: | High Gradient Plate Magnetic Separator |
|---|---|---|---|
| Magnetic Field Intensity: | High | Maintenance: | Easy |
| Working Environment: | Wet | Magnetic Field Distribution: | Uniform |
| Material: | Steel | Magnetic Strength: | High |
| Condition: | New | After-sales Service Provided: | Video Technical Support,commissioning And Training,Online Support |
| Warranty: | 2 Years | Type: | Magnetic Separator |
| Dimension(l*w*h): | 4600x2600x1700 Mm | Application: | Ironplant,pyrrhotite,magnetic Separator,Ore/iron/sand,slag Plant |
| Capacity: | 15-20tph | Product Name: | Magnetic Separator,iron Separator,iron Separator For Mining And For Rare Earth,Factory Price Mineral Separation Wet And Dry Drum Magnetic Separator |
| Power(w): | 2.5kw |
We recently developed an advanced series of high gradient and high intensity magnetic separators. This series features a permanent high strength magnetic flat type separator that is mainly used for the separation of 1.2 mm fine non-metallic minerals, such as nepheline, quartz and feldspar. In addition to these minerals, it can also be used to remove iron impurities while purifying red iron ore (hematite, limonite, garnet and siderite, etc.), manganese ore, ilmenite, and kaolin.
Specification:
| Model | Magnetic Separation Area Size | Processing Capacity | Feed Concentration | Highest Magnetic Field Strength | Granularity | Power |
| ZT-0815P | 800*1500mm | 5-8t/h | 20%-25% | 9000-14000gs | <2mm | 1.1kw |
| ZT-1020P | 1000*2000mm | 7-10t/h | 20%-25% | 9000-14000gs | <2mm | 1.5kw |
| ZT-1525P | 1500*2500mm | 10-15t/h | 20%-25% | 9000-14000gs | <2mm | 2.2kw |
| ZT-1530P | 1500*3000mm | 12-18t/h | 20%-25% | 9000-14000gs | <2mm | 3.0kw |
| ZT-2025P | 2000*2500mm | 16-20t/h | 20%-25% | 9000-14000gs | <2mm | 4.0kw |
| ZT-2030P | 2000*3000mm | 18-22t/h | 20%-25% | 9000-14000gs | <2mm | 5.5kw |
The Superconducting High-Gradient Magnetic Separation Technology is mostly used for the extraction and purification of 1.2mm fine non-metallic minerals, such as nepheline, quartz, and feldspar.
It is also useful for removing impure iron elements from some mineral ores, including red iron ore (hematite, limonite, garnet and siderite, etc.), manganese ore, ilmenite, and kaolin.
Brand Name: ZT
Model Number: ZT-1525P
Place of Origin: Foshan, Guangdong, China
Certification: ISO9001
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Exporting Package
Delivery Time: Within 35 days after downpayment
Payment Terms: L/C,T/T
Supply Ability: 50 sets per month
Maintenance: Easy
Magnetic Field Distribution: Uniform
Working Environment: Wet
Magnetic Field Intensity: High
Magnetic Field Direction: Vertical
Highlighted Keywords: Wet Plate Magnetic Separator, Permanent Plate Magnet Machine, Iron Plate Magnetic Separator
High Gradient Magnetic Separator technical support and services include:
The High Gradient Magnetic Separator is carefully packaged for shipment. The packaging materials used include foam, paper, wooden box, corrugated cardboard, bubble wrap, etc. The package should be strong enough to protect the product during transport.
The shipping method of High Gradient Magnetic Separator is air or sea. The shipping time and cost will depend on the shipping destination. The customer will be informed of the estimated shipping time and cost before the product is shipped.
