Product Details:
|
| After-sales Service Provided: | Online Support,Video Technical Support | Condition: | New |
|---|---|---|---|
| Type: | Magnetic Separator | Warranty: | 12 Months |
| Production Capacity: | 2-4TPH | Application: | Ore,Chemical Industry And Construction,Quarry |
| Power(w): | 1.1-11kw | Installation: | Under Guidance |
| High Light: | magnetic roll separator,metal separation equipment |
||
Belt Conveyor Iron Ore Electro Magnetic Roller Separator Machine Uninterrupted Duty
l Product introduction
Self-discharging electromagnetic belt separator RCDD series is designed for long term operating shift provided with self-discharge function and semi-sphere shaped magnetic field. Installed with continuous operating trump iron discharging conveyor which helps to throw the attracted magnetic material into the iron collection tray. It is suitable for removing the magnetic iron particles from the thicker bed of the material and material under bigger granularity such as ores, coals, hard cokes, limestone and etc.
l Product features
1. Used to remove iron particles from material
2. Self-discharging tramp iron/metal
3. Uninterrupted duty
4. Japanese production standard
5. Half sphere shaped magnetic field
6. Moving conveyor for unloading
l Main technical data
|
Product capacity(T) |
4-10 |
|
Magnetic field intension(GS) |
15000 |
|
Magnetic roller specification(mm) |
φ100 X 800 |
|
Power(KW) |
1.5 |
|
Input voltage(V) |
380 |
|
Motor rotation quantity(RPM) |
1390 |
|
Belt rotation quantity(cycle/min) |
46 |
