Product Details:
|
| Model: | 3A160 | Magnetic Field Strength（T）: | 2 |
|---|---|---|---|
| Inputvoltage（ACV）: | 380 | Insulation Method: | E |
| Cooling Method: | Water And Oil Double Cooling | Magnetic Lumen Diameter（mm）: | 160 |
| Yield（T）: | 0.5-1.5 | Dimension（mm）: | 700*700*1450 |
| Main Machine Weight （KG）: | 450 | Usage: | Applicable For 60-300 Mesh Feedstock Of Iron Elimination |
| Highlight: | magnetic separator for grinding machine,magnetic roll separator |
||
Dry Electromagnetic Iron Separator for Gypsum Powder
Technical parameter:
| Model | WG160B-V-3 | WG220B-V-3 | WG300-V-7 | WG220B-V-11 | WG430-V-11 | WG220-V-15 | WG600-V-20 |
| Magnetic field strength(t) | 2 | 2 | 3 | 3 | 3 | 5 | 3 |
| Input voltage(VAC) | 380 | 220 | 380 | 380 | 380 | 380 | 380 |
| Maximun output current(A) | 15 | 7 | 20 | 20 | 20 | 30 | 40 |
| Maximum coil power(KW) | 3 | 3 | 7 | 11 | 11 | 15 | 20 |
| Insulation category | E | E | E | E | E | E | E |
| Cooling method | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling |
| Magnetic lumen diameter(mm) | 160 | 220 | 300 | 220 | 430 | 220 | 600 |
| Yield(m3/h) | 0.5-1.5 | 43833 | 1.5-4 | 0.5-3 | 1.5-6 | 1-3 | 3-8 |
| Dimension(mm) | 700*700 | 860*860 | 1320*1320 | 1300*110 | 1500*1500 | 1350*1100 | 1500*1500 |
| *1450 | *1540 | *2500 | *1800 | *2500 | *1850 | *2000 | |
| Main machine weight(kg) | 450 | 490 | 1020 | 1130 | 1210 | 1500 | 2000 |
| Usage | 60-300 mesh feedstock of iron elimination | ||||||
Application
1.Concentrating of dry, granular minerals such as ilmenite, garnet, monazite, walframite, columbite, tantalite, etc.
2.Separation and removal of minerals of low magnetic susceptibility from cassiterite, zircon, shellite, rutile, etc.
3.Efficient and clean separation of cassiterite from mixture of other minerals .
4.Specific gravity differences are not sufficiently large for effective gravitational wet process to be effective.
5.Separation of Garnet and Monazite from Zircon.
6.The removal of feebly magnetic particles from swart.
7.Purification of abrasives.
8.Purification of quartz for the glass making industry.
9.Extraction of iron oxides from chemicals and various food products.
