380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate

380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate
380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate 380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate 380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate 380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate 380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate

Large Image :  380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate

Product Details:
Place of Origin: FOSHAN,GUANGDONG,CHINA
Brand Name: ZT
Certification: ISO9001:2008
Model Number: WD-7A300
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Film And Wooden Case
Delivery Time: Within 30 days after the advance payment is made
Supply Ability: 50 SETS PER MONTH

380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate

Description
Model: 7A300 Magnetic Field Strength(T): 3
Inputvoltage(ACV): 380 Maximum Output Current(DCA): 20
Maximum Coil Power(KW): 11 Insulation Method: E
Cooling Method: Water And Oil Double Cooling Magnetic Lumen Diameter(mm): 300
Yield(T): 1.5-4 Dimension(mm): 1320*1320* 2500
Main Machine Weight (KG): 1020 Usage: Applicable For 60-300 Mesh Feedstock Of Iron Elimination
High Light:

Electro magnetic Separator

,

induced roll magnetic separator



380V Electromagnetic Separator Water And Oil Double Cooling CE





Product characteristic



High strength and high reliability

Large wrap angle and multi-magnetic-pole.

With the mechanical vibrating equipment

Easier to discharge the iron.





Operation process



380V Electromagnetic Separator ,Feed the dry powder from the hopper, meanwhile make the separator state at the magnetizing and run a vibrator. After a period ,stop feeding, cut off the magnetic device, run the other vibrator(keep the two vibrator running), poke the raffle of drain of material funnel into the iron discharge. Then discharge the magnetic material absorbed on the magnetic media relying on the vibrating force.





Technical parameter of contrast



Model

3A160

3A220

11A220

11A430

15A220

20A600

Magnetic field strength(T)

2

2

3

3

5

3

Input voltage(ACV)

380

220

380

380

380

380

Maximum output current(DCA)

15

7

20

20

30

40

Maximum coil power(KW)

3

3

11

11

15

20

Insulation method

E

E

E

E

E

E

Cooling method

water and oil double cooling

water and oil double cooling

water and oil double cooling

water and oil double cooling

water and oil double cooling

water and oil double cooling

Magnetic lumen diameter(mm)

160

220

220

430

220

600

yield(T)

0.5-1.5

1-3

0.5-3

1.5-6





dimension(mm)

700*700*1450

860*860*

1540

1300*1100*

1800

1500*1500*

2500

1350*1100*

1850

1500*1500*

2000

Main machine weight

(KG)

450

490

1130

1210

1500

2000

Usage

Applicable for 60-300 mesh feedstock of iron elimination





Application scope



1. 380V Electromagnetic Separator  are applied in process the fine mineral particle, the magnetic fine ferrous mineral particle such as  hematite, martite, limonite, siderite, chromite, polianite; and also fine nonferrous metals mineral particle, for example wolframite; fine rare earth mineral particle, for example eremite; and fine nonmetallic mineral particle such as feldspar, quartz, kaolin. 2. Electromagnetic dried-powder separators are suitable for using at the drought and water shortage area.

For example:Kaolin Beneficiation,Sodium potassium feldspar  Beneficiation,Quartz Beneficiation  ,Polarity powder material Beneficiation ,pharmacy  treatment,active pharmaceutical ingredient(API)treatment,antibiotics treatment,paper treatment ,paper pulp treatment,fiber stuff treatment,organic chemical industry and  related equipment  ,Fine chemicals and  related equipment.



380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate 0



380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate 1



380V Electromagnetic Separator Water And Oil Double Cooling CE Certificate 2
