Durable Automatic 1000mm Magnetic Iron Separator , Magnetic Separation Equipment

Large Image : Durable Automatic 1000mm Magnetic Iron Separator , Magnetic Separation Equipment

Product Details:

Place of Origin:	FOSHAN,GUANGDONG,CHINA
Brand Name:	ZT
Certification:	ISO9001:2008
Model Number:	model 1000

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	Negotiable
Packaging Details:	Film and wooden case
Delivery Time:	Within 10 days after the advance payment is made

Contact Now

Durable Automatic 1000mm Magnetic Iron Separator , Magnetic Separation Equipment

Description

High Light:

drum type magnetic separator

wet high intensity magnetic separator

Durable Automatic 1000mm Magnetic Iron Separator Energy Efficient

Introduction:

Automatic Oil-cooling Eletromagnetic Slurry Separator which is new-developed
by our engineer and is the combination of the requirement of non-metalic industry
and the advantage of large volume magnetic separator around China and the world.

With the pritical application, we can see a positive effect on the beneficiation of Mica,
Ti and Fe2O3 that those non-metallic are hard to be beneficated nomally.

Meanwhile,those machines can increase production by 3-8 times, and gained many recognition

and support from customer.

Advantages:

Output voltage can be adjusted

A new model of separator with high efficiency.

Adopt water oil double cooling

More energy efficient

Easy to manual and maintain.

Technology parameter

Model	1000 Water-cooling Electromagnetic Slurry Automatic Iron Remover	1000 Oil-cooling Electromagnetic Slurry Automatic Iron Rmover
Input voltage(ACV)	380	380
Maximum output current(DCA)	2500	280
Maximum coil power(KW)	180	0-120
Cooling method	Water-cooling	Water and oil double cooling
Magnetic lumen diameter(mm)	1000	1000
Pipe size	200	219
Yield(m³/h)	80-200	80-200
Dmension(mm)	271024103500	314026803300
Main machine weight(KG)	35000	22000

Durable Automatic 1000mm Magnetic Iron Separator , Magnetic Separation Equipment 0

Tag:

Contact Person: Mr. Bobby Tan

Tel: +86 15363435052

Fax: 86-757-85430267

Other Products

Dry Powder Electric Magnetic Iron Separator For Non Ferrous dried powder feldspar chemical food medicine

Name: non ferrous metal separator

Magnetic field strength（T）: 2

Inputvoltage（ACV）: 380

Maximum coil power（KW）: 3

1.5kw 380v Magnetic Separator Machine Magnetic Separation Conveyor belt sorter

Program Controlled Water Cooling magnetic separator machine 30000 Gauss

Color: Blue and grey

Coil Material: Copper

Cooling Method: Water-cooled

Magnetic Intensity: 30000 gauss adjustable

380ACV wet high intensity magnetic separation equipment For Kaolin China Clay Ceramic Clay

Model: ZT-1000-V

Magnetic field strength(T): 3

Input voltage(ACV): 380

Maximum output current(DCA): 2500

1000mm Magnetic Separation Equipment / Magnetic Separator For Oil - Cooling

Input voltage（ACV）: 380

Maximum output current（DCA）: 280

Maxiumum coil power（KW）: 0-120

Cooling method: Water cooling and oil-cooling
