2.5T Water Cooling Electromagnetic Separator Kaolin Feldspar Mine

2.5T Water Cooling Electromagnetic Separator Kaolin Feldspar Mine
2.5T Water Cooling Electromagnetic Separator Kaolin Feldspar Mine 2.5T Water Cooling Electromagnetic Separator Kaolin Feldspar Mine

Large Image :  2.5T Water Cooling Electromagnetic Separator Kaolin Feldspar Mine

Product Details:
Place of Origin: Foshan,Guangdong, China (Mainland)
Brand Name: ZT
Certification: ISO9001:2008
Model Number: WS-1000-V Automatic Water-Cooling Slurry
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Film and wooden case
Delivery Time: Within 35 days after the advance payment is made
Payment Terms: T/T or L/C
Supply Ability: 50pcs per month

2.5T Water Cooling Electromagnetic Separator Kaolin Feldspar Mine

Description
Model: WS-1000-V Voltage: 380
Power(W): 150 Magnet Field Intensity: 2.5T
Insulation Category: E Cooling Method: Water Cooling
Pipe Size: 200mm Weight: 26000kg
Dimension(L*W*H): 3052*2185*2814
High Light:

2.5T Water Cooling Electromagnetic Separator

,

2.5T Electromagnetic Separator

,

Kaolin Feldspar Mine magnetic Separator

2.5T Water Cooling Electromagnetic Separator Kaolin Feldspar Mine



Popular marketing Water Cooling Magnetic Separator Machine , High Gradient Magnetic Separator kaolin feldspar mine Electromagnetic  Magnetic Separator Machine Automatic Water Cooling for Slurry 2.5T





Specifications



1. High field strength and large gradient,
2. Strong magnetic force,

3. An obvious efficiency in iron remove.

4. Applying water to cool the machine





Product characteristic



Model WS500-V WS750-V WS1000-V WY750-V WY1000-VB WY1200-V WY1500-V
Magnetic field strength(T) 2 2.5 2.5 2 2 2.5 3
Input voltage(ACV) 380 380 380 380 380 380 380
Maximum coil power(KW) 75 103 150 82 120 150 180
Insulation method E E E E E E E
Cooling method water cooling water cooling water cooling oil cooling oil cooling oil cooling oil cooling
Magnetic lumen diameter(mm) 500 750 1000 750 1000 1200 1500
Pipe size(mm) 100 150 200 150 200 250 300
yield(m³/h) 20-45 30-65 50-100 30-65 50-100 50-150 70-180
dimension(mm)

2328*1745*

2642

2659*1978*

2518

3052*2185*

2814

2958*2294*

3091

3503*2658*

3392

3950*2926*

3746

4349*3180*

3706

Main machine weight 14000 16600 26000 16000 28000 53000 65000
(KG)
Usage Applicable for 40-400 mesh feedstock of iron elimination





Operation process


Firstly, power on, then open the admission valve and slurry valve, close the return slurry valve and iron discharging valve, then magnetizing. After a few minutes later(you can set the time whatever you like depending on yourself condition),close the admission valve and slurry valve, open the back slurry valve to discharge the remaining slurry in the separator, then magnetic cutting, close the admission valve, slurry valve and back slurry valve, open the iron discharging valve to discharge the magnetic material which are absorbed on the magnetic media.




Application scope


Automatic Water-cooling Eletromagnetic Slurry Separator Series: It is used for purifying the non-metallic mineral such as quartz, feldspar and kaolin.
Ferrous metals mineral: hematite, martite, limonite, siderite, chromite, polianite.
Non-ferrous metals mineral: used for separating wolframite from pyrope
Rare earth ore: recycle tantalum-niobium ores and monazite.
other industries: iron ore, effluent of power station disposal, disposal of contaminated chemical raw material.





Description



1. Work magnetic source using high magnetic energy product and dielectric materials with high gradient, high field intensity, big gradient, strong magnetic force.

Uniform distribution, the density of soft magnetic medium has greatly increased the capture probability of ferromagnetic impurities in pulp.

Due to the resistance of dielectric materials can make the iron slurry is longer than the time slowly through the magnetic field in a row, effectively remove of strong magnetic impurities and part of the weak magnetic iron oxide and titanium oxide, improve product whiteness, in order to achieve the ideal effect of iron removal.

2. PLC control, continuous work, automatically remove iron, automatic cleaning, cleaning time and cycle are adjustable, high reliability, long service life.

3. High intensity magnetic iron absorption, demagnetization wash, iron clean, less water, can remove working medium inspection, cleaning, effectively avoid cross effects of different size.

4. The host is not electricity, low use cost, achieving energy saving and environmental protection, high efficiency on iron removal.



The client's processing pictures

2.5T Water Cooling Electromagnetic Separator Kaolin Feldspar Mine 02.5T Water Cooling Electromagnetic Separator Kaolin Feldspar Mine 12.5T Water Cooling Electromagnetic Separator Kaolin Feldspar Mine 2
