Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity

Customer Reviews
Product was sent very quickly and arrived on time and in good shape. Packaging was good to insure no damage to the unit.

—— Joseph Camara Jr.

great product ,great price arrived as expected

—— Darrin Lynn

I saved money (30%) by getting this at this website versus a local company. Works good looks bigger in photos but worth the price

—— William H.

Works great! Highly recommend.

—— gus ott

I'm Online Chat Now

Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity

Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity
Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity
Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity

Large Image :  Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity

Product Details:
Place of Origin: Foshan.China
Brand Name: ZT
Certification: ISO9001:2008
Model Number: WS-1000-V
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Film and wooden case
Delivery Time: Within 45 days after the advance payment is made
Payment Terms: T/T, Western Union
Supply Ability: 50 SETS

Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity

Description
Model: WS-1000-V Magnetic Field Strength(T): 2.5
Input Voltage(ACV): 380 Maximum Output Current(DCA): 2500
Maxiumum Coil Power(KW): 150(Adjustive) Insulation Method: E
Lumen Diameter (mm): 1000 Pipe Size(in): 8
Capacity(m³/h): 50-100 Weight(T): 26
Dimension(mm): 3052*2185*2814
High Light:

2.5T Electromagnetic Separator

,

180KW Electromagnetic Separator

,

2.5T High intensity Separator


Automatic Water cooling Magnetic Equipment main for non-metallic and ceramics slurry,efficent intelligent Iron Remover


Foshan Zhongtai Machinery Company Limited provide customers with convenient services ,meantime,though the research platform cooperation and communication with people in the technology industry ,continues update the whole line science solutions of non-metallic mineraI.As a have technology and marketing services high-tech enterprise, Zhongtai Limited industry provides high-quality products, advanced production technology,excellent product quality ,perfect after- service and the support and trust from customers around the world.To up the ;set up national famous brands, moving towards the world- class enterprise.




Product characteristic

A new model of separator with high efficiency.
High intensity magnetic field.
The temperature inside of the machine rises slowly.
Running long time and the magnetic field intensity are not easy to decrease.

Technology parameter



Model WS500-V WS750-V WS1000-V WY750-V WY1000-VB WY1200-V WY1500-V
Magnetic field strength(T) 2 2.5 2.5 2 2 2.5 3
Input voltage(ACV) 380 380 380 380 380 380 380
Maximum coil power(KW) 75 103 150 82 120 150 180
Insulation method E E E E E E E
Cooling method water cooling water cooling water cooling oil cooling oil cooling oil cooling oil cooling
Magnetic lumen diameter(mm) 500 750 1000 750 1000 1200 1500
Pipe size(mm) 100 150 200 150 200 250 300
yield(m³/h) 20-45 30-65 50-100 30-65 50-100 50-150 70-180
dimension(mm)

2328*1745*

2642

2659*1978*

2518

3052*2185*

2814

2958*2294*

3091

3503*2658*

3392

3950*2926*

3746

4349*3180*

3706

Main machine weight 14000 16600 26000 16000 28000 53000 65000
(KG)
Usage Applicable for 40-400 mesh feedstock of iron elimination



Operation process

 After a few minutes later(you can set the time whatever you like depending on yourself condition),close the admission valve and slurry valve, open the back slurry valve to discharge the remaining slurry in the separator, then magnetic cutting, close the admission valve, slurry valve and back slurry valve, open the iron discharging valve to discharge the magnetic material which are absorbed on the magnetic media.
Application scope

Non-metallic mineral: It is used for purifying the non-metallic mineral such as quartz, feldspar and kaolin.
Non-ferrous metals mineral: used for separating wolframite from pyrope
Rare earth ore: recycle tantalum-niobium ores and monazite.
other industries: iron ore, effluent of power station disposal, disposal of contaminated chemical raw material.

The customers processing pictures as below:



Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity 0



Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity 1



Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity 2Automatic Water Cooling 180KW 2.5T Electromagnetic Separator with High Output Capacity 3
