Product Details:
|
| Magnetic Field Strength（T）: | 3 | Input Voltage（ACV）: | 380 |
|---|---|---|---|
| Maximum Output Current: | 20 | Maximum Coil Power（KW）: | 11 |
| Insulation Method: | E | Cooling Method: | Water And Oil Double Cooling |
| Magnetic Lumen Diameter（mm）: | 300 | Yield（T）: | 0.5-3 |
| Dimension（mm）: | 1300*1100* 1800 | Main Machine Weight （KG）: | 1130 |
| High Light: | magnetic separator for grinding machine,metal separation equipment |
||
We are the Leading Manufacturer,Supplier and Exporter of Magnetic Drawer Housing in China.Which is Manufactured from high quality stainless steel, these products are highly appreciated for their excellent performance, easy installation, and low maintenance. These drawer magnet units are available with multiple rows for effective operations. The individual rows can be removed for cleaning purposes. In addition to this, our customers can avail this product at standard prices.
Features:
Applications:
Technical parameter
| Model | WG160B-V-3 | WG220B-V-3 | WG300-V-7 | WG220B-V-11 | WG430-V-11 | WG220-V-15 | WG600-V-20 | |
| Magnetic field strength(t) | 2 | 2 | 3 | 3 | 3 | 5 | 3 | |
| Input voltage(VAC) | 380 | 220 | 380 | 380 | 380 | 380 | 380 | |
| Maximun output current(A) | 15 | 7 | 20 | 20 | 20 | 30 | 40 | |
| Maximum coil power(KW) | 3 | 3 | 7 | 11 | 11 | 15 | 20 | |
| Insulation category | E | E | E | E | E | E | E | |
| Cooling method | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | |
| Magnetic lumen diameter(mm) | 160 | 220 | 300 | 220 | 430 | 220 | 600 | |
| Yield(m3/h) | 0.5-1.5 | 43833 | 1.5-4 | 0.5-3 | 1.5-6 | 1-3 | 3-8 | |
| Dimension(mm) | 700*700 | 860*860 | 1320*1320 | 1300*110 | 1500*1500 | 1350*1100 | 1500*1500 | |
| *1450 | *1540 | *2500 | *1800 | *2500 | *1850 | *2000 | ||
| Main machine weight(kg) | 450 | 490 | 1020 | 1130 | 1210 | 1500 | 2000 | |
| Usage | 60-300 mesh feedstock of iron elimination | |||||||
