Water Cooling Slurry Equipment Fully Automated Operation Efficent Low Energy Intelligence Kaolin Feldspar Ceramic Slurry

Water Cooling Slurry Equipment Fully Automated Operation Efficent Low Energy Intelligence Kaolin Feldspar Ceramic Slurry
Water Cooling Slurry Equipment Fully Automated Operation Efficent Low Energy Intelligence Kaolin Feldspar Ceramic Slurry Water Cooling Slurry Equipment Fully Automated Operation Efficent Low Energy Intelligence Kaolin Feldspar Ceramic Slurry

Large Image :  Water Cooling Slurry Equipment Fully Automated Operation Efficent Low Energy Intelligence Kaolin Feldspar Ceramic Slurry

Product Details:
Place of Origin: Foshan.China
Brand Name: ZT
Certification: ISO9001:2008
Model Number: WS-1000-V
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Film and wooden case
Delivery Time: Within 30 days after the advance payment is made
Payment Terms: T/T, Western Union
Supply Ability: 30 SETS per month
Contact Now

Water Cooling Slurry Equipment Fully Automated Operation Efficent Low Energy Intelligence Kaolin Feldspar Ceramic Slurry

Description
Model: 1000 Magnetic Field Strength(T): 2.5
Input Voltage(ACV): 380 Maximum Output Current(DCA): 2500
Maxiumum Coil Power(KW): 150 Insulation Method: E
Cooling Method: Water Cooling Magnetic Lumen Diameter(mm）: 1000
Yield(m³/h）: 50-100 Dimension（mm）: 3052*2185*2814
Weight（KG): 26000
Highlight:

drum type magnetic separator

,

wet high intensity magnetic separator

Water-cooling automatic electromagnetic slurry separator equipment

Foshan Zhongtai Machinery Company Limited is a national high-tech enterprise, owns a number of invention patents, with research and development production, major products are: magnetic separator for non-metallic mineral raw materials, ceramic glaze, metal, plastics, food and all kinds of industries. The main products are: electromagnetic Slurry separator, electromagnetic powder machine, permanent magnetic separator vertical ring electromagnetic separator, vertical ring permanent magnetic separator and different sizes of magnetic plates, magnetic rod, drawer type magnetic separator etc; Our company possesses professional technical team and sophisticated laboratory, can be customized for magnetic separator. Since 2014 Zhongtai Limited got involved in domestic and international mineral processing engineering technology and the fields of whole line project design etc.


Water Cooling Slurry Equipment Fully Automated Operation Efficent Low Energy Intelligence Kaolin Feldspar Ceramic Slurry 0


Features:

  • Durable
  • Easy to operate
  • High performance
  • Touch Screen Interface
  • Easy-to-Use, Fully Automated Operation

Technology parameter



Model WS500-V WS750-V WS1000-V WY750-V WY1000-VB WY1200-V WY1500-V
Magnetic field strength(T) 2.0 2.5 2.5 2.0 2.0 2.5 3.0
Input voltage(ACV) 380 380 380 380 380 380 380
Maximum coil power(KW) 75 103 150 82 120 150 180
Insulation method E E E E E E E
Cooling method water cooling water cooling water cooling oil cooling oil cooling oil cooling oil cooling
Magnetic lumen diameter(mm) 500 750 1000 750 1000 1200 1500
Pipe size(mm) 100 150 200 150 200 250 300
yield(m³/h) 20-45 30-65 50-100 30-65 50-100 50-150 70-180
dimension(mm) 2328*1745*2642 2659*1978*2518 3052*2185*2814 2958*2294*3091 3503*2658*3392 3950*2926*3746 4349*3180*3706
Main machine weight 14000 16600 26000 16000 28000 53000 65000
(KG)
Usage Applicable for 40-400 mesh feedstock of iron elimination




Application scope

Non-metallic mineral: It is used for purifying the non-metallic mineral such as quartz, feldspar and kaolin.
Ferrous metals mineral: hematite, martite, limonite, siderite, chromite, polianite.
Non-ferrous metals mineral: used for separating wolframite from pyrope
Rare earth ore: recycle tantalum-niobium ores and monazite.
other industries: iron ore, effluent of power station disposal, disposal of contaminated chemical raw material.

 Water Cooling Slurry Equipment Fully Automated Operation Efficent Low Energy Intelligence Kaolin Feldspar Ceramic Slurry 1



Water Cooling Slurry Equipment Fully Automated Operation Efficent Low Energy Intelligence Kaolin Feldspar Ceramic Slurry 2
