Magnetic Separation Material Handling Equipment For Black Powder 440v

China Magnetic Separation Material Handling Equipment For Black Powder 440v supplier

Large Image :  Magnetic Separation Material Handling Equipment For Black Powder 440v

Product Details:

Place of Origin: FOSHAN.CHINA
Brand Name: WDY
Certification: ISO9001:2008
Model Number: WG430-V-11

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Film And Wooden Case
Delivery Time: Within 20 days after the advance payment is made
Contact Now
Detailed Product Description
Model: 11A430 Magnetic Field Strength(T): 3
Inputvoltage(ACV): 380 Maximum Output Current(DCA): 20
Maximum Coil Power(KW): 11 Insulation Method: E
Cooling Method: Water And Oil Double Cooling Magnetic Lumen Diameter(mm): 430
Yield(T): 1.5-6 Dimension(mm): 1500*1500* 2500
Main Machine Weight (KG): 1210 Usage: Applicable For 60-300 Mesh Feedstock Of Iron Elimination



Magnetic Separation Material Handling Equipment For Black Powder 440v



Force Magnetic Solution independent development Powder Separators for remove iron from such as silica sand, flour and quartz sand, ceramic powder,etc powder as well as small pieces; powder separation with its outstanding features full-automation,easy and fast operation.Separation powder is the most popular magnetic machine for mining,recycling,ceramic industry etc. Powder separators apply for 40-200 mesh powder material, simple configuration, easy installation, strong magnetic performance, long service life, safe and convenient,high yield, highly effective.



Magnetic Separation Material Handling Equipment For Black Powder 440v



Parameter

Model WG160B-V-3 WG220B-V-3 WG300-V-7 WG220B-V-11 WG430-V-11 WG220-V-15 WG600-V-20
Magnetic field strength(t) 2 2 3 3 3 5 3
Input voltage(VAC) 380 220 380 380 380 380 380
Maximun output current(A) 15 7 20 20 20 30 40
Maximum coil power(KW) 3 3 7 11 11 15 20
Insulation category E E E E E E E
Cooling method water and oil cooling water and oil cooling water and oil cooling water and oil cooling water and oil cooling water and oil cooling water and oil cooling
Magnetic lumen diameter(mm) 160 220 300 220 430 220 600
Yield(m3/h) 0.5-1.5 43833 1.5-4 0.5-3 1.5-6 1-3 3-8
Dimension(mm) 700*700 860*860 1320*1320 1300*110 1500*1500 1350*1100 1500*1500
*1450 *1540 *2500 *1800 *2500 *1850 *2000
Main machine weight(kg) 450 490 1020 1130 1210 1500 2000
Usage 60-300 mesh feedstock of iron elimination
