ISO Permanet Magnetic Separator Rod Drawer Type 220V 380V 400V 440V

China ISO Permanet Magnetic Separator Rod Drawer Type 220V 380V 400V 440V supplier

Large Image :  ISO Permanet Magnetic Separator Rod Drawer Type 220V 380V 400V 440V

Product Details:

Place of Origin: FOSHAN,GUANGDONG,CHINA
Brand Name: WDY
Certification: ISO9001:2008
Model Number: Drawer Type Magnetic Separator

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: film and wooden case
Delivery Time: 55 days
Payment Terms: T/T, Western Union
Supply Ability: 1000 set
Contact Now
Detailed Product Description

Permanet Magnetic Rod Drawer Type Magnetic Separator 220V 380V 400V 440V



The Drawer Magnets are designed to remove metal contamination from free flowing, gravity or mechanical fed material in enclosed flow lines. They incorporate high power Magnetic Cartridges into their design and are suitable for various industries including plastics, food, pharmaceutical, powders, grain and more.


Product Description

The magnetic drawer are constructed by a group of magnetic grates and housing. It would be one layer or multiple layers inside the housing which depend on the material condition. Usually, a magnetic drawer is installed into the pipeline. So mounting way have to be decided by customer.


 Features:
1. Finishing: Fine polishing and well welding to meet food grade.
2. Material: All the frames and housing are stainless steel with seamless steel tube
3. Magnet: High strength rare-earth Magnet.
4.Working Temperature: Standard magnetic drawer working temperature is ≦ 80℃, but if higher temperature is required, we can offer up to 350℃ to meet your special applications
5. Type of mounting: Round or Square, flange or quick release clamp are decided by customer
6. As rare earth magnets are extremely powerful and tramp metal is very difficult to remove by hand. We are ready to offer you an easy-clean design type drawer magnet.
7. Customer designs, specifications can be fulfilled.


Technology parameter



Product Diameter(mm) Pieces Layer

8-layer Drawer type magnetic separator

Ф25

36

8

6-layer Drawer type magnetic separator

Ф32

33

6

5-layer Drawer type magnetic separator

Ф25

23

5

4-layer Drawer type magnetic separator

Ф32

18

4

3-layer Drawer type magnetic separator

Ф32

11

3





ISO Permanet Magnetic Separator Rod Drawer Type 220V 380V 400V 440VISO Permanet Magnetic Separator Rod Drawer Type 220V 380V 400V 440V
