Product Details:
|
| Operation: | Automatic | Size: | 4200X3600X1700mm |
|---|---|---|---|
| Magnetic Field Distribution: | Uniform | Material: | Steel |
| Working Environment: | Wet | Maintenance: | Easy |
| Magnetic Strength: | High | Magnetic Field Intensity: | 12000-15000 Gauss |
| Mineral Processing: | Iron, Hematite, Limonite, Chromite, Quartz Sand |
Our latest research and development of magnetic separator equipment is the series permanent high strength magnetic flat type separator. It is mainly used for non-metallic minerals, such as nepheline, quartz and feldspar, in a finest size of 1.2mm. Additionally, this device can also work on purifying red iron ore (hematite, limonite, garnet and siderite, etc.), manganese ore, ilmenite and kaolin while removing iron impurities.
High Frequency Vibrating Screen is a type of equipment widely used in mineral processing.
It is mainly used for screening and sorting 1.2 mm fine non-metallic minerals, including nepheline, quartz and feldspar. Furthermore, it is applied to remove iron impurities from minerals like red iron ore (e.g.hematite, limonite, garnet and siderite), manganese ore, ilmenite and kaolin.
Specification:
| Model | Magnetic Separation Area Size | Processing Capacity | Feed Concentration | Highest Magnetic Field Strength | Granularity | Power |
| ZT-0815P | 800*1500mm | 5-8t/h | 20%-25% | 9000-14000gs | <2mm | 1.1kw |
| ZT-1020P | 1000*2000mm | 7-10t/h | 20%-25% | 9000-14000gs | <2mm | 1.5kw |
| ZT-1525P | 1500*2500mm | 10-15t/h | 20%-25% | 9000-14000gs | <2mm | 2.2kw |
| ZT-1530P | 1500*3000mm | 12-18t/h | 20%-25% | 9000-14000gs | <2mm | 3.0kw |
| ZT-2025P | 2000*2500mm | 16-20t/h | 20%-25% | 9000-14000gs | <2mm | 4.0kw |
| ZT-2030P | 2000*3000mm | 18-22t/h | 20%-25% | 9000-14000gs | <2mm | 5.5kw |
Brand Name: ZT
Model Number: ZT-1530P
Place of Origin: Foshan, Guangdong, China
Certification: ISO9001
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Exporting Package
Delivery Time: Within 35 days after downpayment
Payment Terms: L/C,T/T
Supply Ability: 50 sets per month
The High Gradient Magnetic Separator is an advanced plate magnetic separator which is mainly used for separating iron ore, iron sand, and other materials. It features a high magnetic field intensity, uniform magnetic field distribution, and a strong magnetic field force. The separator is made of high-quality steel for long-lasting durability.
The separator can easily remove iron ore, iron sand, and other impurities from various materials, making it an ideal choice for industries such as mining, metallurgy, chemical processing, and ore processing. This Plate Magnetic Separator is highly effective and efficient, and can be used to separate iron plate, iron sand, and other materials.
The High Gradient Plate Type Magnetic Separator is a great choice for separating iron ore, iron sand, and other materials. It features high magnetic field intensity, uniform magnetic field distribution, and a strong magnetic field force. The separator is made of high-quality steel for long-lasting durability. It is a great choice for industries such as mining, metallurgy, chemical processing, and ore processing.
We offer a comprehensive technical support and service package for our High Gradient Magnetic Separator. Our service and support includes:
Our experienced and dedicated service team is on hand to provide you with the highest level of customer care.
The High Gradient Magnetic Separator is packaged and shipped in sturdy, robust boxes designed to ensure that the device arrives undamaged and in perfect condition.
The package also includes additional cushioning material to protect the inside contents from any external shocks during transit. We also provide a tracking number for customers to keep an eye on their shipment.
A1: Our High Gradient Magnetic Separator is ZT-1525P produced by ZT.
A2: Our High Gradient Magnetic Separator is produced in Foshan, Guangdong, China.
A3: The minimum order quantity of our High Gradient Magnetic Separator is 1 Set.
A4: Yes, our High Gradient Magnetic Separator has ISO9001 certification.
A5: The delivery time of our High Gradient Magnetic Separator is within 35 days after downpayment, and the payment terms is L/C,T/T.
