|Magnetic Field Strength（T）:||3||Inputvoltage（ACV）:||380|
|Maximum Output Current（DCA）:||40||Maximum Coil Power（KW）:||20|
|Insulation Method:||E||Cooling Method:||Water And Oil Double Cooling|
|Magnetic Lumen Diameter（mm）:||600||Yield（T）:||3-8|
|Dimension（mm）:||1500*1500*2000||Main Machine Weight （KG）:||2000|
magnetic separator for grinding machine,
magnetic roll separator
Kaolin Beneficiation Dry Drum Type Magnetic Separator Machine Low Noise
Electromagnetic dried-powder separator is a newly development machine.The characteristics of magnetic system are large wrap angle, multi-magnetic-pole. The absolute value of magnetic flux density of separation area is evenly.
We can design different magnetic field intensity as the property of raw ores. Also, dried-powder separator doesn’t need to come over the gravity and resistance of the raw material.
When the nonmagnetic minerals break away from the magnetic field, it can depart from the magnetic cylinder very well. With the mechanical vibrating equipment, it not only can improve the efficiency of iron remove but also can be easier to discharge the iron.
Feed the dry powder from the hopper, meanwhile make the separator state at the magnetizing and run a vibrator.
After a period ,stop feeding, cut off the magnetic device, run the other vibrator(keep the two vibrator running), poke the raffle of drain of material funnel into the iron discharge.
Then discharge the magnetic material absorbed on the magnetic media relying on the vibrating force.
Electromagnetic dried-powder separators are applied in process the fine mineral particle.
The magnetic fine ferrous mineral particle such as hematite, martite, limonite, siderite, chromite, polianite;
Fine nonferrous metals mineral particle, for example wolframite;
Fine rare earth mineral particle, for example eremite; and fine nonmetallic mineral particle such as feldspar, quartz, kaolin.
Electromagnetic dried-powder separators are suitable for using at the drought and water shortage area.
For example:Kaolin Beneficiation,Sodium potassium feldspar Beneficiation,Quartz Beneficiation ,Polarity powder material Beneficiation,active pharmaceutical ingredient(API)treatment,antibiotics treatment,fiber stuff treatment,organic chemical industry and related equipment ,Fine chemicals and related equipment.
|Magnetic field strength(t)||2||2||3||3||3||5||3|
|Maximun output current(A)||15||7||20||20||20||30||40|
|Maximum coil power(KW)||3||3||7||11||11||15||20|
|Cooling method||water and oil cooling||water and oil cooling||water and oil cooling||water and oil cooling||water and oil cooling||water and oil cooling||water and oil cooling|
|Magnetic lumen diameter(mm)||160||220||300||220||430||220||600|
|Main machine weight(kg)||450||490||1020||1130||1210||1500||2000|
|Usage||60-300 mesh feedstock of iron elimination|
Main equirement Finished product
selected Magnetic materials
