Product Details:
|
| Swivel Outer Diameter（mm）: | 1750 | Ore Size（mm）， （-200 %）: | -1.2（30-100） |
|---|---|---|---|
| Ore Density（%）: | 10-40 | Ore Pulp Transit Capability（m³/h）: | 50-100 75-150 |
| Dry Ore Throughput（t/h）: | 30-50 | Rated Background Magnetic Field（T）: | 1.0 |
| Rated Energizing Current （A）: | 1200 | Rated Energizing Voltage（V）: | 31 |
| Rated Exciting Power（Kw）: | 37 | Rotaing Pulsation Power（Kw）: | 4 |
| Pulse Stroke（mm）: | 1-30 | Water Supplied Speed（Mpa）: | 0.2-0.3 |
| Water Consumption（m³/h）: | 80-120 | Cooling Water Processing（m³/h）: | 4-5 |
| Weight Of Biggest Parts（T）: | 11 | Dimension（length X Wide X Height，mm）: | 3900x3300x3800 |
| High Light: | magnetic roller separator,drum magnetic separator |
||
Metal Inline Magnetic Particle Separator Magnetic Iron Separator Save Energy
Vertical Ring High Gradient Magnetic Separator
Professional mining equipment for mineral concentration/dressing/beneficiation/refining/brightening/purification
Functions of magnetic separator (WHIMS):
1. Concentrate fine, feebly magnetic minerals, such as hematite, limonite, siderite, ilmenite, chromite, wolframite, tantalum niobium, tungsten, cassiterite, etc.
2. Purifying (iron and titanium removal) nonmetallic minerals such as quartz, feldspar, nephelite, fluorite, sillimanite, spodumene, kaolin, etc.
We offer:
- Mineral specimens test for free
- Tailored magnetic separator
- Considerate service
Technical parameter
|
Model |
WD-1250 |
WD-1500 |
WL1750T |
WD-2000 |
|
Swivel outer diameter(mm) |
1250 |
1500 |
1750 |
2000 |
|
Ore size(mm), (-200 mesh %) |
-1.2(30-100) |
-1.2(30-100) |
-1.2(30-100) |
-1.2(30-100) |
|
Ore density(%) |
10-40 |
10-40 |
10-40 |
10-40 |
|
Ore pulp transit capability(m³/h) |
20-50 |
50-100 |
75-150 |
100-200 |
|
Dry ore throughput(t/h) |
10-18 |
20-30 |
30-50 |
50-80 |
|
Rated background magnetic field(T) |
1.0 |
1.0 |
1.0 |
1.0 |
|
Rated energizing current(A) |
850 |
950 |
1200 |
1200 |
|
Rated energizing voltage(V) |
23 |
29 |
31 |
35 |
|
Rated exciting power(Kw) |
19 |
27 |
37 |
40 |
|
Swivel rotating power(Kw) |
1.5 |
3 |
4 |
5.5 |
|
Rotating pulsation power(Kw) |
2.2 |
4 |
4 |
7.5 |
|
Pulse stroke(mm) |
0-20 |
0-30 |
0-30 |
0-30 |
|
Pulse speed(times/min) |
0-300 |
0-300 |
0-300 |
0-300 |
|
Water consumption(Mpa) |
0.15-0.3 |
0.2-0.3 |
0.2-0.3 |
0.2-0.3 |
|
Water consumption(m³/h) |
30-45 |
60-90 |
80-120 |
100-150 |
|
Cooling water processing(m³/h) |
2.5-3 |
3-4 |
4-5 |
5-6 |
|
Weight of biggest parts(T) |
4 |
5 |
11 |
14 |
|
dimension(length x width x height,mm) |
3200x2340x2700 |
3600x2900x3200 |
3900x3300x3800 |
4200x3550x4200 |
Application Range
Separation of weak magnetic minerals, such as: hematite, limonite, siderite, chromite, titanic iron ore, scheelite, wolframite, manganese and tantalum-niobium ores, etc.
For iron separation from nonmetallic minerals, such as quartz, feldspar, nepheline, fluorite, sillimanite, spodumene and kaolin, etc.
