Product Details:
|
| Magnetic Field Strength（T）: | 3 | Input Voltage（ACV）: | 380 |
|---|---|---|---|
| Maximum Output Current: | 20 | Maximum Coil Power（KW）: | 11 |
| Insulation Method: | E | Cooling Method: | Water And Oil Double Cooling |
| Magnetic Lumen Diameter（mm）: | 300 | Yield（T）: | 0.5-3 |
| Dimension（mm）: | 1300*1100* 1800 | Main Machine Weight （KG）: | 1130 |
| High Light: | wet drum magnetic separator,wet high intensity magnetic separator |
||
Technical parameter
| Model | 3A160 | 3A220 | 7A300 |
11A220 |
11A430 | 15A220 | 20A600 |
| Magnetic field strength(t) | 2 | 2 | 3 | 3 | 3 | 5 | 3 |
| Input voltage(VAC) | 380 | 220 | 380 | 380 | 380 | 380 | 380 |
| Maximun output current(A) | 15 | 7 | 20 | 20 | 20 | 30 | 40 |
| Maximum coil power(KW) | 3 | 3 | 7 | 11 | 11 | 15 | 20 |
| Insulation category | E | E | E | E | E | E | E |
| Cooling method | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling | water and oil cooling |
| Magnetic lumen diameter(mm) | 160 | 220 | 300 | 220 | 430 | 220 | 600 |
| Yield(m3/h) | 0.5-1.5 | 1-3 | 1.5-4 | 0.5-3 | 1.5-6 | 1-3 | 3-8 |
| Dimension(mm) |
700*700 *1450 |
860*860 *1540 |
1320*1320 *2500 |
1300*110 *1800 |
1500*1500 *2500 |
1350*1100 *1850 |
1500*1500 *2000 |
| Main machine weight(kg) | 450 | 490 | 1020 | 1130 | 1210 | 1500 | 2000 |
| Usage | 60-300 mesh feedstock of iron elimination | ||||||
