5 Layer Permanent Magnetic Separator Grill Drawer Type 23 Piece 32mm 380VAC 220VAC

5 Layer Permanent Magnetic Separator Grill Drawer Type 23 Piece 32mm 380VAC 220VAC
5 Layer Permanent Magnetic Separator Grill Drawer Type 23 Piece 32mm 380VAC 220VAC 5 Layer Permanent Magnetic Separator Grill Drawer Type 23 Piece 32mm 380VAC 220VAC 5 Layer Permanent Magnetic Separator Grill Drawer Type 23 Piece 32mm 380VAC 220VAC 5 Layer Permanent Magnetic Separator Grill Drawer Type 23 Piece 32mm 380VAC 220VAC

Large Image :  5 Layer Permanent Magnetic Separator Grill Drawer Type 23 Piece 32mm 380VAC 220VAC

Product Details:
Place of Origin: FOSHAN,GUANGDONG,CHINA
Brand Name: ZT
Certification: ISO9001:2008
Model Number: 5-layer Semi-Automatic Drawer Type Magnetic Separator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: film and wooden case
Delivery Time: Within 25 days after the advance payment is made
Payment Terms: T/T, Western Union
Supply Ability: 1000 set

5 Layer Permanent Magnetic Separator Grill Drawer Type 23 Piece 32mm 380VAC 220VAC

Description
Voltage: 220V/380V Condition: New
After-sales Service Provided: Video Technical Support,Online Support Warranty: 12 Months
Type: Magnetic Separator Weight: 750kg-3000KG
Dimension(l*w*h): Various Size Production Capacity: High Level
Power(w): 1.5-11kw Application: Ironplant,magnetic Separator,Ore/iron/sand
Capacity: 1.5~7.5 T/h Product Name: Magnetic Separator,iron Separator,iron Separator For Mining And For Rare Earth
High Light:

low intensity magnetic separator

,

conveyor magnetic separator

5 Layer Magnetic Grill Drawer Type 23 Piece 32mm 380VAC 220VAC


Product Description
Magnetic Grill (Drawer Type) can be fitted simply in existing pipe line or outlet of various equipments like Pulveriser, blenders or any other outlet location. In standard type each unit comprises to permanent magnetic grill mounted one above the other. System with multiple grill (Layer) are available for special application. The grill are easily removable for cleaning.


General features of magnets (drawer magnets)

  • Special applications of these goods made them suitable for multiple usages. These systems are so much great to use because of their multiple grids.
  • These magnets are fitted in the already existing pipelines which have various components on the outlet of the device. Blenders like equipments use these equipments or magnets by some simple techniques.
  • Permanent magnets have grids which are taken care with the technique of mounting. One over the other unit makes it more capable than any other magnets.
  • This is really easy to remove these grids from the equipment. While cleaning of machines, this factor helps us a lot.
  • manifold grids are present
  • their availability is possible due to their manifold grids
  • drawers are pulled without lots of efforts
  • handles and diverse varieties of drawer magnets separate the contaminated molecules from the needed items
  • gravity conveying system is applicable in real manner
  • separation task of the varieties handles with certain types


Technology parameter
5 Layer Magnetic Grill Drawer Type 23 Piece 32mm 380VAC 220VAC


ProductDiameter(mm)PiecesLayer

8-layer Drawer type magnetic separator

Ф25

36

8

6-layer Drawer type magnetic separator

Ф32

33

6

5-layer Drawer type magnetic separator

Ф25

23

5

4-layer Drawer type magnetic separator

Ф32

18

4

3-layer Drawer type magnetic separator

Ф32

11

3



Where can we apply drawer magnets?

  • In the recovery of shots, we can use these magnets.
  • for the processing of minerals
  • industries related to medicines or pharmaceutical industry
  • industry of mining
  • recycling of tires
  • recycling of rubbers
  • industry of food processes
  • these magnets are applicable in the chemical processes
  • small scale industries use these magnets in their several sections
  • cement industry
  • gypsum sectors or industrial areas

5 Layer Permanent Magnetic Separator Grill Drawer Type 23 Piece 32mm 380VAC 220VAC 0

5 Layer Permanent Magnetic Separator Grill Drawer Type 23 Piece 32mm 380VAC 220VAC 1
