Product Details:
|
| Magnetic Field Strength（T）: | 3 | Input Voltage（ACV）: | 380 |
|---|---|---|---|
| Maximum Output Current: | 30 | Maximum Coil Power（KW）: | 50 |
| Insulation Method: | E | Cooling Method: | Oil Cooling |
| Magnetic Lumen Diameter（mm）: | 430mm | Yield（T）: | 4-6 |
| Dimension（mm）: | 2414*2100*2400 | Main Machine Weight （KG）: | 11500 |
| High Light: | Quartz Powder Dry Magnetic Separator,Kaolin Magnetic Separator Machines,430mm Dry Magnetic Separator |
||
Company profile:
Foshan Zhongtai Machinery Company Limited provide customers with convenient services, meantime,though the research platform cooperation and communication with people in the technology industry ,continues update the whole line science solutions of non-metallic mineraI.As a have technology and marketing services high-tech enterprise, Zhongtai Limited Wanda industry provides high-quality products, advanced production technology,excellent product quality , perfect after- service and the support and trust from customers around the world.To up the ;set up national famous brands, moving towards the world- class enterprise.
Advantages:
Technical parameter:
| Model | WG300-V-25 | WG430-V-25 | WG430-V-50 |
| Magnetic field strength(t) | 2.5 | 2.5 | 3.5 |
| Input voltage(VAC) | 380 | 380 | 380 |
| Maximun output current(A) | 47 | 47 | 100 |
| Maximum coil power(KW) | 25 | 25 | 50 |
| Insulation category | E | E | E |
| Cooling method | oil cooling | oil cooling | oil cooling |
| Magnetic lumen diameter(mm) | 300 | 430 | 430 |
| Yield(m3/h) | 1-2 | 2-3 | 4-6 |
| Dimension(mm) | 1600*1500 | 1750*1650 | 2414*2100 |
| *2075 | *2075 | *2400 | |
| Main machine weight(kg) | 2100 | 2200 | 11500 |
| Usage | 60-300 mesh feedstock of iron elimination | ||
